Product Details:
|
| Manufacturer: | SINOTRUK (CNHTC) | Series:: | HOWO |
|---|---|---|---|
| Product Name:: | Refuse Compactor, Garbage Truck, Garbage Collection Truck, Garbage Compactor | Chassis Model:: | ZZ3257M3841 |
| Drive Type:: | 6X4, LHD | Engine:: | WD615.69, 336HP, Euro II |
| Tank Vol.: | 2.5m3 | Loading Capacity:: | 20tons |
| Cabin:: | HW76,1 Beth | Transmission:: | HW19710 |
| High Light: | 12cbm Refuse Compactor Truck,10cbm Refuse Compactor Truck,12cbm Garbage Truck |
||
Our refuse compactors (waste compactors) are widely used to compact household garbage, commercial wastes and industrial refuse of nonhazardous and with no rusty and no radioactivity.
With payloads of 3—15 tons, the machine is designed with both hand and automatic controls system with the specialties of large volume, high efficiency, better sealing and easy for service so that they are widely used in municipal refuse handling, commercial and industrial garbage operations.
Main Parameter of new refuse compactor trucks:
| Vehicle Main Dimensions | Cab type | howo cab, single sleeper, 2 passengers, air conditioning |
| Overall dimension(L×W×H)(mm) | 9280,8950X2496X3380(mm)mm | |
| Steering type | Left Hand Drive or RHD with ZF8098 power steering | |
| Max. Drive Speed (km/h) | 90 | |
| Curb weight (kg) | 11870 | |
| Chassis parameter | Chassis manufacturer | cnhtc |
| Transmission | Manual , HOWO 10 forward and 2 reverse | |
| Brakes | air brake | |
| Tire | 11.00-20 with 1 spare tire | |
| Engine parameter | Engine brand | cnhtc |
| Model | WD615.97 | |
| Fuel type | Diesel | |
| Horse Power(kw)/(hp) | 221kw/300hp | |
| Displacement(ml) | 9726ml | |
| Superstructure Parameter | volume(m3) | 10-12m3 |
| Compartment material | side and back 4mm ,floor 5mm carbon steel | |
| Standard Configuration | loading hopper, front push , rear compressed , sewage tank, with sewage water tank, rearhanging bucket overturn mechanism, | |
| Control method | Electronic Control in the cab and manual control on the body side |
1. The hydraulic system adopted double-pump double-loop structure which avoided system heating phenomenon and thus reduced power dissipation.
2. The garbage truck adopts both manual and automatic hydraulic control system;
3. L-type sealing ribbon and hydraulic locking device is adopted and thus effectively guaranteed the sealing between the feeding machine and the carriage and avoided sewage leaking;
4. High compression ratio for the wastes are compressed by two sides;
5. Fuel saving: While feeding wastes, the motor will accelerate synchronously;
6. Stable operation and low noise.
By Roro or Bulk or Flat Rack Container according to your specific requests.
1, the whole truck warrenty is 1 year or 50000km, base on whichever comes first.
2, professional sevice team, enough spare parts to make you away from future worries.
3, professional trainning teachers for your drivers or engineers on repair and maintenance
