Product Details:
|
| Use: | Truck Trailer | Type: | Dump Trailer |
|---|---|---|---|
| Material: | Steel | Certification: | CE/ADR/DOT |
| Size: | 11500mm*2500*2850mm | Max Payload: | 40-100 Tons |
| Axle Brand: | Fuwa/BPW | Axle Loading: | 13,16,20,22 Tons |
| Suspension: | Mechanical/Air Suspension | Tire: | 11.00r20 Or 12r22.5 |
| King Pin: | 2"(50mm)or3.5"(90mm) JOST | Landing Gear: | JOST Brand Two-speed |
| Leaf Spring: | 90(W)mm*13(Thickness)mm*10(Layer) | Vehicle Paingting: | Electrophoresis Paint |
| Dump Box: | Bottom 4 Mm Side 3 Mm | Lifting Cylinder: | HYVA |
| High Light: | 40T Truck Dump Trailer,HYVA Truck Dump Trailer,40T dump semi trailer |
||
Truck Dump Trailer Semi Dump Trailer Capacity Or Semi Trailer End Dump Truck Capacity
| Dump Style | Rear Dump |
| Loading Capacity | 40T-100T |
| Axle | 2/3/4 Axle 13/16T CIMC/FUWA/BPW |
| Length*Width*Height | 12500mm*2500mm*2800mm |
| Cylinder | HYVA |
| Floor Plate Thickness: | 5mm |
| Sidewall Thickness: | 4mm |
| ITEM | SPEC. |
| Main Beam Material | Q345/T700 |
| Main Beam Height | 500mm |
| Main Beam Upper Plate | 14mm |
| Main Beam Middle Plate | 8mm |
| Main Beam Lower Plate | 16mm |
| Axle | 2/3/4 Axles 13/16T CIMC/FUWA/BPW |
| Tire | 11.00R20/12R222.58/12/16 pieces Linglong/Triangle/Double-Coin/Bridgestone |
| Rim | 8.0/9.0*8/12/16 pieces, steel/aluminum |
| Suspension | Mechanical/Air suspension |
| Leaf Spring | 90mm*13/16mm*10 pieces |
| Landing Gear | JOST 28T two-speed |
| King Pin | JOST 2”(50#)/3.5”(90*) changeable |
| Tool Box | Steel/Aluminum |
SINOTRUK TRUCK DUMP TRAILER
