336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck

336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck
336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck

Large Image :  336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck

Product Details:
Place of Origin: China
Brand Name: SINOTRUK HOWO
Certification: ISO/3C/BV/IFA/SGS
Model Number: ZZ3317N4267
Payment & Shipping Terms:
Minimum Order Quantity: 1unit
Price: US$38000-USD48000/unit
Packaging Details: Nude, Waxing in RORO or bulk ship
Delivery Time: 20-30 working days after deposit or LC
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 units per month

336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck

Description
Manufacturer: SINOTRUK (CNHTC) Series:: HOWO
Product Name:: Dump Truck (Tipper) Model:: ZZ3317N4267
Drive Type:: 8X4, LHD Engine:: WD615.47, 371HP, Euro II
Cargo Body:: 7800×2300×1500mm Loading Capacity:: 40-60tons
Cabin:: HW76,1 Beth Transmission:: HW19710
High Light:

336hp SINOTRUK Tipper Truck

,

40t SINOTRUK Tipper Truck

,

12 Wheeler SINOTRUK Tipper Truck

SINO SINOTRUCK 336hp 371hp SINOTRUK 8x4 40 Ton Howo Tipper Truck 12 Wheeler 40t Howo Dump Truck Price

Sinotruk Howo 50 Ton 8x4 Brand New 12 Wheeler Dump Tipper Truck Price



SINOTRUK HOWO Tipper Truck, the best choice for you!



336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 0

SINOTRUK (CNHTC) HOWO heavy duty trucks--the most advanced and most superior new generation of heavy duty trucks in China, with proprietary brand and intellectual property right, was developed by SINOTRUK (CNHTC) by applying the world advanced heavy duty truck key technology aiming at the market of the world.



HOWO heavy duty truck is with luxury and great appearance; it is a combination of fortitude and streamline, sturdiness and elegance. It aims at world heavy duty truck level on the ergonomic design like comfortability, safety and accessibility.



The launch of HOWO heavy duty truck embodied the enterprise operation philosophy of SINOTRUK (CNHTC) of pursuing the optimized customer value constantly. It will make the customer be proud of his correct option by its strong working ability, pleasurable interior and exterior trimmings, and better safety, comfortability, easy to operate, low fuel consumption and easy to maintain.




336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 1

China Sinotruk howo dump truck 8x4 drive 12 wheeler 30ton Tipper truck with best price

Sinotruk Howo Products Advantages:
1.Rich Experience in sale of the Sinotruk’s heavy equipment & truck.
2.Expert in kinds of sinotruk heavy trucks and spare parts.
3.Personalized customization to meet your working requirements.
4.High quality of Original parts & OEM services.
5.Engineers and experts on call for pre/after sale support.
6.One-stop service with sinotruk heavy trucks, parts as well as stand-by advice & support.
Chassis Model
ZZ3317N4867A/S0WA-5
Driving Type
8X4
Sinotruk Howo
Cabin
HW76—HOWO Extended cabin. Basic configuration is with single sleeper; new type seat; adjustable steering wheel from up and down,
front and rear ; new type integral warm air heater with European style; the German VDO instrument which synchronized with the
world high level heavy duty truck; road vehicles is with four point floating suspension (front spiral spring, rear air spring)
with shock absorbers, off road vehicles is with four point floating spring suspension + shock absorbers, each type of cabin is
with transverse stabilizing device, double lock safety belt; external sunshade; fourth generation air conditioning, air
conditioning control board is liquid crystal display with LED lighting; with cruise; with sound warning system for abnormal
generator voltage (to prevent damage of electronic devices); electric windows.
Sinotruk Howo
Engine
Make: SINOTRUK
Diesel 4-stroke direct injection diesel engine
Engine model: WD615.47, 371HP ;
Emission :Euro 2
6-cylinder in-line with water cooling, turbo-charging and intercooling
Displacement: 9.726 L
Transmission
HW19710, 10F & 2R,HW50
Steering
ZF power steering, modol ZF8118, hydraulic steering with power assitance
Front Axle
HF9,1x9000 KGS
Steering with doubleT-cross section beam
Rear Axle
HC16, 2x16000 KGS
Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles.
Ratio:5.73
Propeller Shaft
Double universal joint propeller shaft with gear-shaped coupling flange
Chassis
Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members
Front suspension:10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer
Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizer
Brake
Service brake: dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels
Auxiliary brake: engine exhaust brake



Electrics
Operating voltage: 24 V, negative grounded
Starter: 24 V, 5.4 Kw
Alternator: 3-phase, 28 V, 1500 W
Batteries: 2 x 12 V, 135 Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light



Tyres
12.00R20, radial tyres with one spare tyre



Fuel Tank
300L



Cargo Body
Length:8.8M;Width:2.3M;Height:1.2-1.8M



Vehicle Size
11445 X 2496 X 3190mm

336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 2

1, mining industry, like copper mine, iron mine, nickel mine, coal mine, etc.



2, construction sites, transport the sand, small stone, etc.



3, farm, to transport cereals



4, others



336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 3

336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 4

SINOTRUK (CNHTC) HOWO series 6x4 dump trucks (tipper trucks) are designed by SINOTRUK comprehensive with the world’s most advanced automotive technology and mature, reliable assembly parts.



Chassis:

1, Engine: HOWO series dump truck equipped with the SINOTRUK mature WD615 Euro II turbocharged water-cooled diesel engine, horse power covering 266-420Ps, fuel consumption lower.

2, Cab: Cab passive-safety performance reaches the world advanced level, the cab installation uses a four-point suspension to make the drivers more high driving comfort;

3, Clutch: Diaphragm spring clutch, diameter 430mm;

4, Brake: WABCO brake system and VOSS connectors, more safe and reliable;

5, Steering: ZF steering system, hydraulic power assistance;

6, VDO electrical instrumentation to improve the reliability of the electrical system

7, Maximum loading capacity can be 40-50tons.

336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 5



Cargo Box:

336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 6





336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 7



336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 8



336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 9

336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 10

By Roro or Bulk or Flat Rack Container according to your specific requests.



336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 11



336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 12

1, the whole truck warrenty is 1 year or 50000km, base on whichever comes first.

2, professional sevice team, enough spare parts to make you away from future worries.

3, professional trainning teachers for your drivers or engineers on repair and maintenance

336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 13





336hp 371hp 8x4 12 Wheeler 40t SINOTRUK Tipper Truck 14
