Product Details:
|
| Manufacturer: | SINOTRUK (CNHTC) | Series:: | HOWO |
|---|---|---|---|
| Product Name:: | Refuse Compactor, Garbage Truck, Garbage Collection Truck, Garbage Compactor | Chassis Model:: | ZZ3257M3841 |
| Drive Type:: | 6X4, LHD | Engine:: | WD615.69, 336HP, Euro II |
| Tank Vol.: | 2.5m3 | Loading Capacity:: | 20tons |
| Cabin:: | HW76,1 Beth | Transmission:: | HW19710 |
| High Light: | 18CBM Compressed Garbage Truck,16CBM Compressed Garbage Truck,371hp Refuse Compactor Truck |
||
Our refuse compactors (waste compactors) are widely used to compact household garbage, commercial wastes and industrial refuse of nonhazardous and with no rusty and no radioactivity.
With payloads of 3—15 tons, the machine is designed with both hand and automatic controls system with the specialties of large volume, high efficiency, better sealing and easy for service so that they are widely used in municipal refuse handling, commercial and industrial garbage operations.
The parameter of Sinotruk HOWO 6x4 371hp 16CBM 18CBM 16M3 18M3 garbage compactor truck compressed garbage truck:
| Item No. | Parameters |
| Overall Dimension | 10290x2496x3270 mm |
| Gross Vehicle Weight | 25000 kg |
| Curb weight | 13650 kg |
| Loading capacity | 16000-20000 kg |
| Wheel Base | 4600+1350 |
| Front axle loading capacity | HF9, 1x9000 kg |
| Rear axle loading capacity | ST16, 2x16000 kg |
| Max Driving Speed | 75 km/h |
| Engine | WD615.87, 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Engine horsepower | 290 HP |
| Emission Standard | Euro II |
| Displacement | 9.726L |
| Gear Box | HW19710, 10 Forwards gear & 2 reverse gear |
| Steering Gear | ZF 8098, power steering, hydraulic steering with power assistance |
| Clutch | Reinforced diaphragm clutch, diameter 430mm |
| Fuel Tank | 400L Aluminum alloy fuel tank |
| Cabin | HOWO 76 Standard Cab, RHD, Right Hand Drive; Two seats with 1 sleeper, with air conditioner, 70° hydraulically tillable to the front. |
| Tire | 12R22.5 Tubeless Tire , 10 pieces with one spare |
| Brake |
Service brake: dual circuit compressed air brake Parking brake: spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake |
| Equipment |
1. Garbage body: 20m3. 2,Equipped with hermetic dustbin, hydraulic system and operating system 3, Automatic compress and uninstall, sewage can be collected by the dump tank. 4. Cycling time<14--18s |
1. The hydraulic system adopted double-pump double-loop structure which avoided system heating phenomenon and thus reduced power dissipation.
2. The garbage truck adopts both manual and automatic hydraulic control system;
3. L-type sealing ribbon and hydraulic locking device is adopted and thus effectively guaranteed the sealing between the feeding machine and the carriage and avoided sewage leaking;
4. High compression ratio for the wastes are compressed by two sides;
5. Fuel saving: While feeding wastes, the motor will accelerate synchronously;
6. Stable operation and low noise.
By Roro or Bulk or Flat Rack Container according to your specific requests.
1, the whole truck warrenty is 1 year or 50000km, base on whichever comes first.
2, professional sevice team, enough spare parts to make you away from future worries.
3, professional trainning teachers for your drivers or engineers on repair and maintenance
