Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer

Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer
Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer

Large Image :  Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer

Product Details:
Place of Origin: China
Brand Name: sinotruk
Certification: SGS/ISO/VGA
Model Number: 9401TD
Payment & Shipping Terms:
Minimum Order Quantity: 1unit
Price: US$10000-$15000
Packaging Details: Nude/Waxed
Delivery Time: 10-15 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 units/month
Contact Now

Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer

Description
Type: Low Flat Semi Trailer Axle: 3-4pcs
Loading: 80 Tons Tyre: 12.00R22.5
Size: 12.5*2.4*1.5 Suspension: Mechanical Or Air
Landing Gear: JOST Brake System: WABCO
King Pin: 2.0 Or 3.5 Inch Color: Customers Optional
High Light:

80 ton Low Bed Trailer

,

70 ton Semi Low Bed Trailer

,

4 Axle Semi Low Bed Trailer







Hot Sale Gooseneck Tri Axles 4 Axle 70 80ton Low Deck Lowbed Semi Trailers



  SINOTRUK TRAILERS



Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 0





















Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 1Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 2Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 3Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 4Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 5

Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 6

Dimensions
13000*3000*(700mm-1200mm) (According to customer demand)
Axle specs.
FUWA ,YAHUA or BPW Brand
Suspension
Mechanical or air supension (American or German)
Rim
6.5-20/8.25-22.5/9.00*22.5 /80-.0-20/8.5-20
King Pin
JOST 2" or 3.5" traction pin
Support legs
JOST, FUWA or YAHUA brand 28T
Wheelbase
7180/6680/6260+1310+1310mm,Or other
Steel Spring
8/8/8, 10/10/10, 12/12/12 pieces per axle
Ladder
Manual or hydraulic automatic
Electrical system
24V, 7 pin socket, One set 7-core standard Cable
Tire
8.25R20/8.25R16/11.00R22.5/12.00R22.5/10.00R20/11.00R20/12.00R20
Spare Tire Carriers
2 pieces
The material of Main beam
Height: 450mm-520mm, upper plate thickness is 14mm-25mm, middle plate thickness is 8mm-12mm, down plate thickness is 16mm-25mm;
Material is Q345 Carbon Steel.
Side beam
16mm-25mm channel steel (Material is Q235 carbon steel)
Platform plate
5/6/7 mm Diamond Plate
Brake
Kemi Brand of China
Brake Chamber
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TAIYUE brand); One piece of 45L air tanks
ABS system
optional
Light
Tail lamp with turn signal, brake light & reflector, side lamp etc
Tool box
1 sets(waterproof type)
Spare tire carrier
1 sets(Patent type)
Painting
Complete Chassis sand blasting to clean rust, 2 coat of anticorrosive primer, 2 coats of final paint
Packing

Polish with wax before shipping





Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 7

Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 8Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 9Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 10Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 11Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 12Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 13Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 14





Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 15Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 16





Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 17

Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 18



Q: Do you have your own factory?

A: We have our own factory in semi trailer production. We sincerely welcome you to visit our factory.



Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.



Q: How about your delivery time?
A: Generally, it will take 15 to 30 days after receiving your advance payment.



Q: Can I paint my logo on trailer?

A: Of course, you can send me your company logo, then we will design it





Gooseneck Tri Axles 4 Axle 70 80 Ton Low Deck Semi Low Bed Trailer 19
