Product Details:
|
| Manufacturer: | SINOTRUK (CNHTC) | Series:: | HOWO |
|---|---|---|---|
| Product Name:: | Concrete Mixer Truck | Chassis Model:: | ZZ1257N3247W |
| Drive Type:: | 6X4, LHD | Engine:: | WD615.47, 371HP, Euro II |
| Mixer Tank Vol.: | 8-15 Cbm | Loading Capacity:: | 25-30 Tons |
| Cabin:: | HW76,1 Beth | Transmission:: | HW19710 |
| High Light: | 10 Wheels SINOTRUK Mixer Truck,HW76 SINOTRUK Mixer Truck,HOWO 6x4 SINOTRUK Mixer Truck |
||
| Chassis Model | ZZ1317N3241W ( Left/right Hand Driving Type) |
| Dimension (L×W×H)mm | 9525*2496*3950mm |
| Wheel base mm | 3200 |
| Cabin | HW76, one sleeper with air-conditioner. |
| Engine | WD615.69, Euro 2, 371HP |
| Transmission | HW15710, 10F & 2R |
| Steering | ZF8118, power steering with hydraulic system. |
| Front Axle | HF9, 1x9000 KGS |
| Rear Axle | HC16, 2x16000 KGS |
| Tyres | 1200R20, 10+1tyres |
| Frame | 8+5 mm double strengthen frame |
| Fuel Tank Volume | 300L |
| Mixer Pump | Eaton (USA Brand) |
| Motor | Eaton (USA Brand) |
| Speed Reducer | Bonfiglioli (Italy Brand) |
| Agitating Capacity | 10-12 Cubic Meters |
| Geometric Volume | 16.5m3 |
| Water Tank Volume | 400L |
| Drum rotating | 11° |
| Agitator rotaion speed | 0-18r/min |
| Feeding speed | >3m3/min |
SINOTRUK has many specialized international advanced level production line-frame, body assembly production and entire vehicle assembly, inspection and so on, and all use of advanced international, domestic leading production, testing facilities, high degree of automation, all can provide a strong support for the building of the model.
Vehicle assembly line is the longest general assembly line of heavy commercial vehicles in Asia. The whole production line is composed of pre line assembly line, trim line, engine assembly line and axle assembly line etc. SINOTRUK has the most advanced fully automatic nut tightening machine, pipe packing machine, transmission shaft packaging and assembly facilities and various liquid filling machines, electrical testing instrument and so on. Guarantee the quality of the vehicle assembly strongly.
First leading advantage: SINOTRUK masters overall R & D core technology and major general component, and has self manufacturing capability
Second leading advantage: Unified technical thinking, unified planning, unified process means, unified quality standard
Third leading advantage: High-end professionals, improve product development chain, which make SINOTRUK unique advantage in domestic heavy-duty automobile product development
