Product Details:
|
Manufacturer: | SINOTRUK (CNHTC) | Series:: | HOWO |
---|---|---|---|
Product Name:: | Refuse Compactor, Garbage Truck, Garbage Collection Truck, Garbage Compactor | Chassis Model:: | ZZ3257M3841 |
Drive Type:: | 6X4, LHD | Engine:: | WD615.69, 336HP, Euro II |
Tank Vol.: | 2.5m3 | Loading Capacity:: | 20tons |
Cabin:: | HW76,1 Beth | Transmission:: | HW19710 |
High Light: | 20 Ton Refuse Compactor Truck,6X4 Refuse Compactor Truck,20 Ton garbage truck |
Our refuse compactors (waste compactors) are widely used to compact household garbage, commercial wastes and industrial refuse of nonhazardous and with no rusty and no radioactivity.
With payloads of 3—15 tons, the machine is designed with both hand and automatic controls system with the specialties of large volume, high efficiency, better sealing and easy for service so that they are widely used in municipal refuse handling, commercial and industrial garbage operations.
25CBM Dongfeng Garbage Compactor Truck | |||||
Specification | |||||
Overall Dimension | 10700×2500×3300 mm | Gross Vehicle Weight | 27000 kg | ||
Curb Weight | 9500 kg | Loading Weight | 16000 kg | ||
Wheel Base | 4350+1300 mm | Front / Rear Axle | 7000 kg / 13000kg | ||
Cabin | Left Hand Driving, 2 Passengers Allowed, with Air Conditioner, Radio, | ||||
Engine | Sino Diesel WD614.87, Four Stroke, 6 Cylinder in line, Mechanical Engine Pump. | ||||
Engine horsepower | 336HP, EURO | ||||
Displacement | 9726 ml/CC | ||||
Max Driving Speed | 90 km/h | ||||
Gear Box | 10 Forward Gear, 1 Reverse Gear, | ||||
Tire | 12R22.5 (10 pieces with one spare) | ||||
Garbage Bin | Capacity | 25 CBM | |||
Material | 6mm Carbon Steel for Garbage Bin Body | ||||
Design | Whole unit with Leakage Proof Design | ||||
Ways of Loading | Rear Loading with optional Bucket Lifting System | ||||
Garbage Compact Ratio | 1/3 - 1/4 | ||||
Control System | One control Panel on the back, One Control system in back of Cabin | ||||
Dispensing System | 1. Equipped with air-tight dustbin, hydraulic system and operating system. 2.Automatic loading, compressing and discharging, all handled by 1 person 3. Sewage water collection tank to avoid any pollution during handling. 4. Large Pressure, Good Leakage Proof, Convenient Operation Dependable Security 5. Electrical Control Panel for compacting system. 6. Cycling time<14~18s |
1. The hydraulic system adopted double-pump double-loop structure which avoided system heating phenomenon and thus reduced power dissipation.
2. The garbage truck adopts both manual and automatic hydraulic control system;
3. L-type sealing ribbon and hydraulic locking device is adopted and thus effectively guaranteed the sealing between the feeding machine and the carriage and avoided sewage leaking;
4. High compression ratio for the wastes are compressed by two sides;
5. Fuel saving: While feeding wastes, the motor will accelerate synchronously;
6. Stable operation and low noise.
By Roro or Bulk or Flat Rack Container according to your specific requests.
1, the whole truck warrenty is 1 year or 50000km, base on whichever comes first.
2, professional sevice team, enough spare parts to make you away from future worries.
3, professional trainning teachers for your drivers or engineers on repair and maintenance
