Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks

Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks
Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks

Large Image :  Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks

Product Details:
Place of Origin: China
Brand Name: SHACMAN
Certification: SGS/VGA/ISO
Model Number: SX4250MXXXXXX
Payment & Shipping Terms:
Minimum Order Quantity: 1unit
Price: US$35000-55000/unit
Packaging Details: Nude, waxing
Delivery Time: 25-30 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000units/month

Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks

Description
Brand: SHACMAN M3000 Drive Type: 6x4, LHD
Model: Tractor Truck, Semi Trailer Towing Engine: Weichai Brand
Emission Level: Euro II, III, IV, V Transmission: FAST F9, F10, F12 Series
Front Axle: 7.5 Ton MAN (drum) Rear Axle: 16 Ton MAN Double Stage Casting
High Light:

6X4 Tractor Truck Head

,

Euro II SHACMAN Trucks

,

Euro III SHACMAN Trucks





SHACMAN Truck China Shacman 6X4 Tractor Head New Brand Trucks Tractor Truck Head



Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks 0

Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks 1

M3000

With a proven design, the M3000 series

is one of the most balanced product.

Lightweight, effiencent and innovative,

the M3000 bring about a new standard

in truck quality.





Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks 2

Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks 3

Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks 4

A Truck You Can Depend On


■ Lightweight European design, precision power matching
■ Optimized intake module decreasing intake resistance by 6%
■ Efficient real axles that increase transmission efficiency by 13%
■ Intercooler resistance reduced by 29%
■ Engine power loss reduced by 8%
■ Efficient tires which reduces rolling resistance by 10%
■ Cooling module developed from adopting German Behr BISS

   simulation software increasing cooling capacity by 10%

Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks 5

Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks 6

Comfortable and Safe


The M3000 series uses brand new European TGS cabin technology with improved cabin tightness, sound proofing and insulation making your work day more enjoyable and safe.


■ European ECE-R29 collision test certified
■ Imported curved high strengh windshield
■ Sedan inspired interior design
■ Spacious interior with 8 new storage locations
■ Sleeping bed width increased to 750mm
■ Telescopic shaft gear shift mechanism

Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks 7

Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks 8



Tractor Truck Head 6X4 LHD Euro II III SHACMAN Trucks 9



China Shacman 6X4 tractor head 365hp brand new trucks for sale

Specifications:

Model SX4257NT324
Make SHACMAN Truck
Drive type 6×4
Application Tractor
Weight
Complete kerb mass (kg) 9400
GVW (kg) 29400
GCW(kg) 60000
Dimensions
Max.length(mm) 6825
Max.width(mm) 2490
Max.heigh(mm) 3710
Front / Rear overhang (Chassis) 1525/725
Wheel base(mm) 3175+1400
Track width(mm) 2036/1800
Performance
Max.speed (km/h) 127
Min.turning circle(m) 15
Min.ground clearance(mm) 314
Approach / Departure angle (°) 22/30
Max.gradeability(%) 34
Engine
Make WEI CHAI
Model WP12.375N
Power(kw/HP) 276/375
Max.Torque (N.m )/rpm 1800/1000—1400
Displacement (L) 11.596
Bore/Stroke (mm) 126/155
Emission Standards Euro
Transmission
Make FAST
Model 12JS180TA
Control type manual
Gear Shift 12-forward and 2 reverse speeds
Option ——
Clutch
Type Single plate, diaphragm spring
Diameter (mm) φ430
Action mechanical pull type, self adjusting Air assisted clutch
Brakes
Type Drum
Service brake With dual-circuit
compressed air brake
Park brake Power spring brake acting
on rear wheel
Auxiliary brake WEVB
Option ABS
Steering
Make Shashi Jiulong
Type Integral inner circulation
power steering
Option ZF8098
Chassis
Type Ladder structure, widened
and cross-section variable
Suspension
Front Suspension semi-elliptic springs with shock absorbers
Rear Suspension inverted leaf spring stabilizator
suspension
Axles
Make SHAAN'XI HANDE
Front axle 7500kg
Rear axle 13000kg(each other)
Double reduction driving axle with
inter-wheel differential and differential lock.
Ratio 3.866(option 4.266)
Option 11500kg(each other)single reduction or 16000kg(each other)double reduction rear axle
Tires
Type (Standard) 12.00-20
Option 12.00R20/11.00-20/11.00R20/12R22.5
Fuel tank
Tank capacity (L) 400
Material Aluminum
Electrics
Type 24V
Starter 6.2kw(24V)
Generator 2.2kw(28V 80A)
Battery 2×135Ah
Cab
Type MAN D'LONG F3000, Lengthened high roof
Equipments 2 rear window, mechanical clerestory, 4 point air suspension, A/C, air suspension driver seat with handle and seatbelts, two sleeping bed, hydraulic reversal cab, with USB can play radio with MP3 format
Option electric windows, electricity heated, GPS or CD, rear-view mirror, Tachograph, car Phone, electricity reversal cab
Other
The fifth wheel 2 inch
saddle ground clearance(mm) 1400
